Suzuki – C-10 Color Multi-Function Display Kit – 990C0-04C10-KIT
Suzuki models from 2013 and after that have engine serial numbers starting with 310001 or higher are compatible with the C10, which is designed for EFI-equipped vehicles.
The Suzuki Color Display (SCD) is a high-resolution LED that is very simple to read. It has front mounting points and can be hooked up to the NMEA 2000 network with a single connection. It is capable of keeping an eye on two engines at once and monitoring such data as RPM, speed, water pressure, fuel level*, fuel consumption, engine temperature, trim, engine hours, and engine voltage.
- Full-color LED is easy to read in bright sunlight and night-time operation
- Fits standard 3 3/8-inch gauge cutout
- Displays data for one or two engines per gauge
- 3 Standard pre-configured** pages do not require user set-up, but they can be customized
- Software updates are made easy with a micro USB
- Power and data are provided through one NMEA 2000 micro-C connector
- Low-profile front mounting points
Applies to the following Suzuki outboards:
- DF 9.9B to DF 350A
- 2013 Model Year and Newer
- May not be compatible with older models
This kit Includes:
- (1) C-10 Color Multi-Function Display
- (1) SMIS Power Cable
- (3) T-Connectors
- (1) Terminating Resistor 120 ohm Female
- (1) Terminating Resistor 120 ohm Male
- (1) SMIS Engine Interface Cable
