nVent TE162024010 Replacement Part
Note: NEMA type 4 interface to Electronic Enclosure Only
Includes:
- (1) – Air Conditioner
- (1) – Bag of Screws & Washers
Specifications
- Voltage(DC): 18-27.6
- CURRENT:
- Cooling Max: 14.1A
- Heating Max: 14.3A
- Fans – Total: 1.4A
- COOLING CAPACITY:
- 24 VDC, 166W, 35 Degrees Celsius
- Temp Min/ Max: -40 Degrees F to 131 Degrees F
- -40 Degrees C to 55 Degrees C
- Min. Circuit Ampacity Cooling: 18 Amps
- Min Circuit Ampacity Heating: 18 Amps
- Approved for outdoor application Type 3R
- Class 2 or SELV power source required
Replaces Old nVent Part Numbers
- There are no older part numbers.
Other Part Numbers
19706B-1609-0001, KACON, 7835102107718, 7 83510 21077 9, Hoffman, Pentair, APW, McLean, nvent
FitsModels:
(Press ctrl + F to find model number below.)
Various. (Call 734-326-3900 with your model and serial number for more information.)
