The Cutler Hammer-Eaton XTOB006CC1 is a bimetallic IEC overload relay designed to provide dependable overcurrent and overload protection for motors in commercial and industrial HVAC applications. Engineered for use with Eaton’s XT IEC contactor series, this relay mounts directly to C frame contactors for a compact, integrated motor starter assembly.
Product Overview
This overload relay offers an adjustable current range of 4–6A, making it well-suited for protecting fractional to small integral horsepower motors commonly found in HVAC fan and pump applications. Its bimetallic trip mechanism provides accurate, temperature-compensated overload detection, helping prevent costly motor burnout and unplanned downtime.
Key Features
- Adjustable overload current range: 4–6A
- IEC-style design for direct mounting to C frame XT series contactors
- Bimetallic trip mechanism with ambient temperature compensation
- Manual and automatic reset capability
- Integrated trip indicator for fast fault diagnosis
- Normally open (NO) and normally closed (NC) auxiliary contacts included
- Compact, space-saving design for panel and enclosure installations
Specifications
- SKU / Part Number: XTOB006CC1
- Brand: Cutler Hammer-Eaton
- Current Range: 4–6A
- Frame Size: C
- Relay Type: IEC Bimetallic Overload Relay
- Series: XT IEC
- Mounting: Direct mount to C frame contactor
- Reset Mode: Manual / Automatic
Applications
- HVAC fan motors and blower motors
- Hydronic circulating pumps
- Commercial refrigeration equipment
- Light industrial motor control panels
- Motor starter assemblies with XT IEC contactors
