Copeland AFE14C5E-IAA-901 115V 1-Phase Low Temp R404A Hermetic Compressor

The Copeland A*E Series represents the pinnacle of hermetic compressor engineering in the 1/8–1/2 HP range (1,000–4,600 BTU/hr). Purpose-built to meet the current and evolving demands of Foodservice, Food Retail, Industrial, and Environmental/Medical applications, the A*E platform delivers an unmatched combination of reliability, efficiency, and total cost of ownership.

Equipped with patented liquid handling technology, these compressors achieve industry-leading performance in a compact hermetic design — making them the top choice for commercial refrigeration in this size class.

Common Applications

• Vertical freezers and reach-in coolers
• Island coolers and bottle coolers
• Vending machines and display cases
• Ice machines and food retail cases

Specifications

• Model: AFE14C5E-IAA-901
• Voltage / Frequency: 115V @ 60Hz
• Phase: Single Phase (1PH)
• Application: Low Temp / Medium Temp
• Compatible Refrigerants: R-404A, R-448A, R-449A, R-452A
• Capacity Range: 997–2,860 BTU/hr
• Cooling Efficiency (EER): Up to 3.75

Key Features

• Patented liquid handling technology for improved reliability and longevity
• Industry-leading EER of up to 3.75 for enhanced energy efficiency
• Compatible with multiple next-generation refrigerants including R-448A and R-449A
• Versatile low and medium temp application range
• Engineered for the best-in-class hermetic compressor performance in its size
