Carrier 320725-757 Replacement Part
Includes:
- (1) – Draft Inducer Motor Assembly (320725-757)
- (1) – Installation Instructions (IIK320725-002)
Specifications
- Manufacturer: Broad-Ocean
- Manufacturer Part : YDZ-040L22541-01
- Horsepower: 1/16
- Voltage: 115
- Hertz: 60
- Number of Phases: 1
- Amps: 0.75
- RPM: 3300
- Rotation: Clockwise Lead End
- Continuous Air Over
- Insulation Class: B
- Thermally Protected
- Capacitor Needed: 3MFD @ 250VAC
- Cooling Fan Part Number: 318977-401
- Motor Part Number: HC28CQ116
- Inducer Housing Part Number: 320725-757 and 319824-403
- Inducer Wheel Part Number: 322592-701
- Wiring Diagram:
- Number of Wires (Including Ground): 5
- Brown Wire: Capacitor
- Brown/White Wire: Capacitor
- Connector Consists of: Green (Ground), White (Common), and Black (Power)
Country of Origin: Vietnam
Replaces Old Carrier Part Numbers
- 320725-754
Other Part Numbers
YDZ-040L22541-01,IIK320725-001, IIK320725-753-001, 319825-402, QCPASSED N5004, N1111171301052, HC28CQ116, 20111115, 318977-401, Inducer Assembly FS, 0 08 22529 38279 1, B/23, Factory Authorized Parts, Replacement Components Division, Carrier Corporation, 322592-701, V5101, V2112103900504, Zhongshan Broad-Ocean Motor Co. , Ltd, 20210910, HC28BCQ116, E256965,
Fits Carrier, Bryant, Payne Models:
(Press ctrl + F to find model number below.)
340AAV060120ACSA, 350AAV060120FCSA, 353AAV060120FBSA, 58MCB120—12120, 58MEB120-F-11120, 58MXB120-F-12120, PG9MAB060120ACSA
